Skid Steer Hydraulic Drive With Rubber Track
The Skid Steer Hydraulic Drive with Rubber Track is a highly versatile and compact machine, equipped with rubber tracks for enhanced traction and a hydraulic drive system for smooth, precise operation. This combination makes it a popular choice for construction, landscaping, and agricultural tasks, especially in environments where maneuverability and minimal ground disturbance are crucial.
Powerful Performance:
Uses hydraulic motors for driving tracks, ensuring efficient power transfer.
Provides consistent torque, making it suitable for demanding tasks.
Smooth and Responsive Control:
Joystick-controlled hydraulic system allows precise speed and directional adjustments.
Independent control of each track for tight turns and skid-steering.
Item Name | 380 |
Working weight of the whole machine(kg) | 870 |
Bucket capacity(m³). | 0.12 |
Traveling speed(Km/h) | 3 |
Max. lifting force(Kg). | 220 |
Max. working height(mm). | 2235 |
Maximum unloading height(mm). | 1340 |
Bucket discharge angle | 25 |
Wheelbase H(mm) ::. | 780 |
Engine model | Brighton |
Maximum flow rate of spare fuel line(L/min) | 65 |
Horsepower hp | 23 |
Nominal speed rpm | 3600 |
Main pump type/model. | Gear pumps |
Maximum flow rate of main pump(L/min). | 65 |
Multi-way valve | 2-way + 3-way manual valves |
Traveling hydraulic motor type. | Cycloidal motors |
Motor displacement(ml) | 375 |
Rubber(bandwidth*pitch*number of sections). | 180*72*37 |
Tensioning type | Hydraulic tensioning |
Total length(mm) | 2250 |
Total width(mm). | 1100 |
Total Height(mm). | 1260 |
Rubber Tracks
Traction and Stability:
Offers superior grip on soft, muddy, or uneven surfaces.
Reduces slippage on slopes and wet conditions.
Minimal Ground Disturbance:
Distributes weight evenly to prevent soil compaction and surface damage.
Durability:
Made from reinforced rubber compounds for long-lasting performance.
Compact Size
Narrow Width:
Typically 3 to 5 feet, making it ideal for confined workspaces.
Lightweight Design:
Easy to transport between job sites using a standard trailer.
Versatile Attachments
Quick-Attach System:
Allows fast swapping of attachments for diverse tasks.
Compatible Attachments:
Buckets (general-purpose, grading, snow)
Augers (for drilling)
Trenchers (for narrow trenching)
Grapples (for debris handling)
Hydraulic breakers (for concrete demolition)
Brooms (for sweeping debris or snow)
